KEY FEATURES
- 8″ Bi-amplified active loudspeaker
- 1.75″ HF compression driver
- 720 w Continuous
- 1440 w Peak
- 127 dB Max SPL @ 1 meter
- 2.5″ LF voice coil
DESCRIPTION
Just like all other Wharfedale Pro plastic active loudspeakers, Typhon uses the largest HF voice coils in their class. All models use a 1.75″ coil HF compression driver.
These custom made Wharfedale Pro compression driver delivers crisp and precise high frequencies, even at extreme volumes.
The internal amplifiers of Typhon have been tuned specifically for the HF and LF drivers that we have chosen. This makes for perfect power and frequency transfer, resulting in the sonic experience that you’d expect from a Wharfedale Pro active loudspeaker.
SPECIFICATIONS
| System Type | Active 8″ 2-way |
| Frequency Response ( /-3 dB) | 65 Hz-20 KHz |
| Frequency Range (-10 dB) | 60 Hz-20 KHz |
| Maximum SPL (peak @1 m) | 127 dB |
| Sensitivity (@ 1 W / 1 m) | 96 dB |
| Low Frequency Transducer | |
| Size (mm / inches) | 203.8 mm / 8” |
| Voice-Coil Size (mm / inches) | 65 mm / 2.5” |
| Rated Impedance | 4 Ω |
| High Frequency Transducer | |
| HF Driver Type | Compression Driver |
| Coil Size (mm / inches) | 44 mm / 1.75″ |
| Exit Size (mm / inches) | 25 mm / 1″ |
| Diaphragm Material | Titanium |
| Rated Impedance | 8 Ω |
| Nominal Coverage (H x V) | Hybrid Symmetry Horn |
| 100°x80° | |
| Amplifiers | 2 x Class D |
| Power Rating | 1440 W Peak (1200 W LF 240 W HF), |
| 720 W Continuous (600 W LF 120 W HF) |
